Rims
Material: 100% carbon fiber with UD external layer
Height: 45 mm
Drilling: co-molded Fore drilled inserts
Disc brake specific profile
Valve hole diameter: 6.5 mm
Tire: UST Tubeless and tubetype
Internal width: 19 mm
ETRTO size: 622x19TC
Spokes
Material: unidirectional carbon fiber
Count: 20 front and rear
Lacing: front and rear crossed 2
R2R carbon spoke technology
Hubs
Front and rear bodies: Carbon
Axle material: Aluminum
Instant Drive 360 freewheel technology
QRM Auto bearing preload technology
Front: Quick release and 12x100 through axle compatible
Rear: Quick Release, 12x142 and 12x135 compatible
Hub available for Center Lock brake rotors only
Versions
Color: Black only
Disc standard: Center Lock® only
Freewheel: Shimano/Sram
Compatibility
Freewheel: Shimano/Sram, convertible to Campagnolo ED11, N3W and XD-R with optional driver bodies
Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters and axle replacement
Front axle: 12x100 thru axle, easily convertible to quick release with optional adapters. Not compatible with 15mm through axles
Compatible Adapters and Freewheel Bodies
12 to 9mm front adapter for quick release (V2680301)
12 to 9mm rear adapter for quick release (V2510801 (with axle V2373401)
12x135 rear axle adapters (V2510901) with axle V2373401
ID360 Shimano / Sram Light freewheel body (V3850101)
ID360 Campagnolo freewheel body (V3440101)
ID360 XD-R freewheel body (V2580101)
ID360 Shimano / Sram freewheel body (V3430101 - Delivered on the wheel)
ID360 N3W freewheel body (V4270101)
Delivered with
Computer magnet (99624501)
User guide
Intended use
ASTM CATEGORY 1 : road only
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels doesn't exceed 120kg, bike included
Maximum Tyre Pressure: 6.75bar/97PSI with a 23mm tyre - 3.8bar/55PSI with a 62mm tyre
Recommended Tyre Sizes: 25 to 32 mm
Max. Pressure: See indication on wheel and tyre. If they differ, use the lowest of the 2
Information on specified weight
The weight of the wheels is announced at +/-5%, in XD/XD-R and Center Lock version, without quick release, nor valve, nor rim tape
