Frame & Fork
Frame: OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel
Fork: RockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock: RockShox Super Deluxe Select+ RT, 205 mm x 60 mm
Wheels & Tyres
Front Wheel: Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear Wheel: Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost 148, 12 mm thru axle
Rear Hub: Bontrager alloy, sealed bearing, 6-bolt, 108T Rapid Drive, SRAM XD driver, Boost148, 12 mm thru axle
Rear Skewer: Bontrager Switch thru-axle, removable lever
Rims: Bontrager Line Elite 30, Tubeless Ready
Tyres: Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Sealant: Bontrager TLR sealant, 180 ml/6 oz
Rim Strip: Bontrager TLR
Gears & Drivetrain
Shifter: SRAM GX Eagle AXS, 12-speed
Rear Derailleur: SRAM GX Eagle AXS
Crank: E*thirteen E*spec Plus, 34T, 165 mm length
Crank Arm: E*thirteen E*spec Race carbon, 34T, 165 mm length
Chainring: SRAM X-SYNC, 32T, alloy
Cassette: SRAM Eagle XG-1275, 10-52, 12-speed
Chain: SRAM GX Eagle, 12-speed
Brakes
Brake Caliper: SRAM Code R 4-piston hydraulic disc
Brake Rotor: SRAM 6-bolt, 200 mm
Components
Saddle: Bontrager Arvada, austenite rails, 138 mm width
Seatpost: Bontrager Line Elite Dropper, 100 mm travel (S), 150mm Travel (M), 200mm Travel (L/XL), MaxFlow, internal routing, 34.9 mm
Integrated Bar Stem: Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35mm stem length
Grips: Bontrager XR Trail Elite, nylon lock-on
Battery & Motor
Battery: TQ 360 Wh
Controller: TQ LED display with Bluetooth & ANT+ connectivity
Motor: TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Charger: TQ 4A charger
Accessories
Charger: SRAM AXS aux power cable
Weight
Weight: M - 18.17 kg / 40.06 lbs (with TLR sealant, no tubes)
Weight Limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
